420ST Gold Stamping 16.5” All-in-one UV DTF Printer

Experience premium quality with the 420ST Gold Stamping 16.5” All-in-one UV DTF Printer. Featuring integrated UV printing and gold stamping functions, this compact solution delivers vibrant colors, metallic effects, and efficient production for labels, crafts, packaging, and customized products. Ideal for small studios and professional print businesses.

Parameter

Print Heads: 4pcs Epson i1600-U1
Printing Width: 16.5”
Print Speed: 8PASS: 3.5㎡/h
Machine Size: L1460*W850*H1320mm
Request a quote

Main Features

State-of-the-art printer built with advanced technology to offer high precision, speed, and stability to your business success.

Stable Data Transmission Ribbon Cable System

The printer is equipped with a high-quality ribbon cable system that ensures fast, stable, and interference-free data transmission between the control board and printhead. Its organized wiring structure improves reliability, reduces signal loss, and enhances long-term printing performance.

High-Precision Linear Motion & Belt Drive

The precision-engineered belt drive and linear motion system provide smooth and accurate printhead movement. This ensures stable printing at high speeds, improves positioning accuracy, and enhances overall print quality for detailed and high-resolution output.

Ink Alarm

The intelligent ink shortage alarm system monitors ink levels in real time and alerts you instantly when ink is running low. This prevents unexpected interruptions, protects the printhead, and ensures smooth, continuous printing for high-volume production.

UV Lamp

The high-intensity UV lamp delivers rapid and uniform curing for UV DTF printing. It enhances ink adhesion, improves surface hardness, and ensures durable, scratch-resistant prints on materials like glass, metal, acrylic, wood, and plastics.

The Epson i1600-U1 is a compact and cost-efficient industrial UV printhead offering impressive print quality and precision. Designed as a mid-range industrial solution, the i1600-U1 provides accurate ink ejection, smooth color reproduction, and dependable performance for small to medium production environments. It is commonly used in UV DTF printers, UV inkjet equipment, and compact industrial printing systems

Epson Printhead

Model I1600-U1
Ink Type UV ink
Max. number of colour inks 4 colours
Number of nozzle 1600
Nozzle pitch /nozzle row 1/300 inches
Nozzle Rows 8 rows
Nozzle Resolution 300npi/1 column 600npi/2 columns
Effective Print Width 33.8 mm (1.33 inches)
Dimensions(LxWxH) 69.1 x 59.4 x 35.6 mm
Weight 80g

Technical Parameter for Printer

Model XF-420ST UV
Printhead and Quantity 4pcs Epson i1600-U1
Printing Speed 8PASS:3.5m²/h
Printing Color W+ CMYK+ V+ Foil Vanish
Printing Width 16.5"
Media Type AB Film, Waste Disposal Film, Hot Stamping Paper
RIP Software Rubber Roller Method
Power / Voltage 3KW;220V/110V;50HZ/60HZ
Machine Size L1460*W850*H1320mm
Packing Size L1480*W1000*H700mm
Net Weight 212KG
Gross Weight 244KG

How does it work?

1

Artwork Preparation

Prepare your design using professional graphic software such as Adobe Photoshop, Illustrator, or CorelDRAW. Export the file in a print-ready format (PNG, TIFF, PDF, AI, etc.).
1

Artwork Preparation

Prepare your design using professional graphic software such as Adobe Photoshop, Illustrator, or CorelDRAW. Export the file in a print-ready format (PNG, TIFF, PDF, AI, etc.).
2

RIP Software Setup

Import the artwork into the RIP software. Adjust key settings including: Color profile Ink limits Print mode Media type
2

RIP Software Setup

Import the artwork into the RIP software. Adjust key settings including: Color profile Ink limits Print mode Media type
3

UV Printing

Load the material (film, acrylic, PVC board, leather, etc.) onto the printer. The UV printer will eject CMYK + White + Varnish ink according to the RIP settings.
3

UV Printing

Load the material (film, acrylic, PVC board, leather, etc.) onto the printer. The UV printer will eject CMYK + White + Varnish ink according to the RIP settings.
4

UV Curing

During printing, the UV LED lamp instantly cures the ink on the surface. This ensures: Fast drying Strong adhesion Scratch resistance Long-lasting durability
4

UV Curing

During printing, the UV LED lamp instantly cures the ink on the surface. This ensures: Fast drying Strong adhesion Scratch resistance Long-lasting durability

Start Printing Effortlessly

Comprehensive service starting from pre-sale to after-sale to help your business on track.

Free Demo & Sample

To show the quality and capability of our printer to satisfy your needs, we will send you a free video demonstration or free samples worth $500, including vulnerable parts, a set of ink / a roll of print film / a kilogram of powder.
flipbox-image

Free Demo & Sample

To show the quality and capability of our printer to satisfy your needs, we will send you a free video demonstration or free samples worth $500, including vulnerable parts, a set of ink / a roll of print film / a kilogram of powder.

Fast Delivery

To meet everyone’s order quickly, we’ve established an overseas warehouse in California, USA. This doesn’t just save time and effort, but also reduces transportation fees. In-stock products can be delivered within 7 days.
flipbox-image

Fast Delivery

To meet everyone’s order quickly, we’ve established an overseas warehouse in California, USA. This doesn’t just save time and effort, but also reduces transportation fees. In-stock products can be delivered within 7 days.

Technical Support

Adequate provision is made for installation and repairs. We offer both online and door-to-door services around the world and also provide manuals and video instructions as extra guides.
flipbox-image

Technical Support

Adequate provision is made for installation and repairs. We offer both online and door-to-door services around the world and also provide manuals and video instructions as extra guides.

Life-time Warranty

You can enjoy a lifetime warranty on all products using our branded inks, which guarantees free spare parts & repairs, software updates, and technical assistance 24/7.
flipbox-image

Life-time Warranty

You can enjoy a lifetime warranty on all products using our branded inks, which guarantees free spare parts & repairs, software updates, and technical assistance 24/7.
