C603+Z650-2 24 Inch 3PCS I3200-A1 Printheads DTF Printer (Gold/Silver hot stamping)

C603+Z650 24 Inch 3PCS I3200-A1 Printheads DTF Printer
  • C603+Z650 24 Inch 3PCS I3200-A1 Printheads DTF Printer
  • C603 DTF PRINTER
  • Z650 POWDER SHAKER

C603+Z650-2 24 Inch 3PCS I3200-A1 Printheads DTF Printer (Gold/Silver hot stamping)

This direct to film printer can apply to various garments, such as t-shirt, hoodies, shoes, spandex underwear, shoes, etc.. With Epson print head, it can print smoothly for your garments or DTF business.

Parameter

Productivity: 6pass:10㎡/h
Printing Width: 24”
Printhead: 3PCS I3200-A1
Dimension: L1660*W750*H1620mm
Request a quote

Main Features

State-of-the-art printer built with advanced technology to offer high precision, speed, and stability to your business success.
24 Inch I3200-A1 DTF Printer

Imported Mute Rail

Equipped with an imported mute rail system, the printer operates with exceptional stability and ultra-low noise. This ensures smoother carriage movement, reduced vibration, and high-precision printing—ideal for professional production environments.

Large Cartridge

The large-capacity cartridge system provides extended printing time and consistent ink flow. Designed for business-level productivity, it minimizes interruptions and supports long, continuous print jobs with reliable color performance.

Leadshine Motone

Powered by a high-performance Leadshine motor, the printer delivers accurate motion control and improved durability. This industrial-grade component enhances printing speed, precision, and long-term operational reliability.

Easy Control Panel

A simplified, intuitive control panel allows operators to manage printing tasks with ease. From monitoring status to adjusting settings, the user-friendly interface improves workflow efficiency for busy printing businesses.

With Precisioncore technology, quick speed, and high resolution, the I3200-A1 printhead is the latest and most efficient model for the textile printer, coming with outstanding nozzles with attributes like automatic cleaning, automatic flash spray, and moisturizing function that keep the printhead free without interruption.

Epson Printhead

Model I3200-A1
Ink Type AQ ink
Max. number of colour inks 4 colours
Number of nozzle 3200
Nozzle pitch /nozzle row 1/300 inches
Nozzle Rows 8 rows
Nozzle Resolution 300npi/1 column 600npi/2 columns
Effective Print Width 33.8 mm (1.33 inches)
Dimensions(LxWxH) 69.1 x 59.4 x 35.6 mm
Weight 82g

Technical Parameter for Printer

Model C603
Printhead and Quantity 3PCS i3200-A1
Printing Color Glue+CMYK+W
Printing Speed 6Pass: 10 m²/h
Printing Width 24"
Media Type DTF Pet Film
RIP Software Standard with Printfactory ,Maintop,RIIN,PhotoPrint,CADlink for Optional
Temperature/Humidity Temperature:20-30 °C Humidity:45-65%
Power 1600W
Voltage 110V /220V
Operating System Windows 11(64bit) / Windows 10(64bit)
Machine Dimension L1660*W750*H1620mm
Package Dimension L2140*W880*H780mm
Net Weight 210KG
Gross Weight 242KG

Technical Parameter for Powder Shaking Machine

Model Z650-2
Retractable Media Width 24"
Rewinding Function Automatic induction winding
Fan Control Shake powder control, dusting control,direction and quantity control
Material Delivery Method Mesh belt conveyor,conductive belt
Heating and Drying Function Efficient and powerful drying and curing
Rated Voltage 220V/110V
Rated Current 40A/80A
Rated Power 3 KW-4.7 KW
Machine Dimension L1750*W1000*H1050mm
Package Dimension L1800*W1030*H1100mm
Net Weight 200KG
Gross Weight 240KG

How does it work?

1

Typeset on Computer

Organize your design pattern on a computer with RIP software for better ink color performance and print characteristics.
1

Typeset on Computer

Organize your design pattern on a computer with RIP software for better ink color performance and print characteristics.
2

Print in Machine

Put the PET film into the printer trays & print the entire image on it. Then, using the color settings in the printer, print the required image on the white layer.
2

Print in Machine

Put the PET film into the printer trays & print the entire image on it. Then, using the color settings in the printer, print the required image on the white layer.
3

Cure ink with Powder

With a powder shaking machine, the adhesive powder can spread evenly on the PET film and dry the graphics
3

Cure ink with Powder

With a powder shaking machine, the adhesive powder can spread evenly on the PET film and dry the graphics
4

Heat Press to Transfer

With the film smoothly laid on the garment, push down the heat press machine to transfer the design pattern.
4

Heat Press to Transfer

With the film smoothly laid on the garment, push down the heat press machine to transfer the design pattern.

Start Printing Effortlessly

Comprehensive service starting from pre-sale to after-sale to help your business on track.

Free Demo & Sample

To show the quality and capability of our printer to satisfy your needs, we will send you a free video demonstration or free samples worth $500, including vulnerable parts, a set of ink / a roll of print film / a kilogram of powder.
flipbox-image

Free Demo & Sample

To show the quality and capability of our printer to satisfy your needs, we will send you a free video demonstration or free samples worth $500, including vulnerable parts, a set of ink / a roll of print film / a kilogram of powder.

Fast Delivery

To meet everyone’s order quickly, we’ve established an overseas warehouse in California, USA. This doesn’t just save time and effort, but also reduces transportation fees. In-stock products can be delivered within 7 days.
flipbox-image

Fast Delivery

To meet everyone’s order quickly, we’ve established an overseas warehouse in California, USA. This doesn’t just save time and effort, but also reduces transportation fees. In-stock products can be delivered within 7 days.

Technical Support

Adequate provision is made for installation and repairs. We offer both online and door-to-door services around the world and also provide manuals and video instructions as extra guides.
flipbox-image

Technical Support

Adequate provision is made for installation and repairs. We offer both online and door-to-door services around the world and also provide manuals and video instructions as extra guides.

Life-time Warranty

You can enjoy a lifetime warranty on all products using our branded inks, which guarantees free spare parts & repairs, software updates, and technical assistance 24/7.
flipbox-image

Life-time Warranty

You can enjoy a lifetime warranty on all products using our branded inks, which guarantees free spare parts & repairs, software updates, and technical assistance 24/7.
