Product Highlights:
1.Wide-Format DTF Printing Capability
Large printing width supports oversized graphics, gang sheets, and batch production—ideal for bulk DTF orders and efficient material usage.
2.Broad Fabric Compatibility
Suitable for nylon, chemical fiber, cotton, leather, and more, delivering stable adhesion and consistent print quality across different materials.
3.High-Quality DTF Output
Ensures rich color performance, clear details, and strong ink bonding. When used with Xinflying DTF ink and powder, prints remain durable and washable.
4.Industrial-Grade Structure
Solid machine construction combined with a stable ink delivery system enables smooth operation and reliable performance for long-term production.
This dtf printer is equipped with a durable silver guide rail designed for smooth and stable carriage movement. It enhances printing precision, reduces vibration, and ensures long-term reliability even during high-speed production.
Engineered for professional DTF printing, the machine features high-performance components, efficient workflow design, and superior output quality. Every detail is optimized to deliver consistent results for business-level production.
The printer uses a CMYK+W color configuration, delivering vibrant, accurate, and high-opacity prints. A dedicated white ink channel provides strong coverage for dark fabrics, ensuring crisp and vivid image quality.
Built-in anti-collision sensors protect the printhead by detecting obstructions during printing. This prevents accidental damage, reduces downtime, and ensures stable, worry-free operation in busy production environments.Industrial-grade internal components ensure durability, stability, and consistent output for DTF printer manufacturers and apparel businesses.
| Model | I3200-A1 |
|---|---|
| Ink Type | AQ ink |
| Max. number of colour inks | 4 colours |
| Number of nozzle | 3200 |
| Nozzle pitch /nozzle row | 1/300 inches |
| Nozzle Rows | 8 rows |
| Nozzle Resolution | 300npi/1 column 600npi/2 columns |
| Effective Print Width | 33.8 mm (1.33 inches) |
| Dimensions(LxWxH) | 69.1 x 59.4 x 35.6 mm |
| Weight | 82g |
| Model | C804 |
|---|---|
| Printhead and Quantity | 4PCS I3200-A1 |
| Printing Speed | 4Pass:25m²/h 6Pass:18m²/h |
| Printing Width | 32" |
| Media Type | DTF Pet Film |
| RIP Software | Standard with Printfactory,Maintop, RIN,PhotoPrint,CAD link for Optional |
| Temperature | 20-30 °C |
| Humidity | 45-65% |
| Power | 1.1KW |
| Machine Dimension | L1950*W820*H1680mm |
| Package Dimension | L2135*W875*H760mm |
| Net Weight | 150KG |
| Gross Weight | 230KG |
Use various design software to design spot color channels.
Use RIP software, color + spot color are RIP out.
DTF Fluorescent printing, dusting, drying the entire process of integrated operation processing, automatic winding.
The printed PET film will be cut manually or cut by cutting machine, and then pressed by hot press, and the film will be finished after tearing.
Q1: What production capacity does this printer support?
A: Suitable for large commercial DTF printing factories.
Q2: Are consumables compatible with other DTF machines?
A: Yes, uses industry-standard DTF consumables.
Q3: Can it run continuously?
A: Yes, industrial-grade components support long operation.
Q4: What support is included?
A: Warranty, spare parts, and remote technical assistance.
