Product Highlights:
1.Hoson Control Board with Smart Monitoring
Equipped with a professional Hoson control board to ensure stable operation, precise printing, and reliable long-term performance.
2.Advanced Ink & Printhead Protection System
Includes automatic ink supply, ink shortage alarm, printhead collision protection, and waste ink monitoring to reduce downtime and maintain print quality.
3.Smart Dual-Pneumatic Rack System
3000mm smart linkage rack with dual pneumatic shafts for smooth material feeding and receiving, ensuring wrinkle-free output.
4.Front & Bottom Intelligent Drying
Integrated drying system at front and bottom to accelerate curing, prevent smudging, and maintain consistent print quality.
5.High-Precision Multi-Head Printing
Equipped with 8pcs Epson i3200-A1 printheads, offering high-resolution printing with excellent color reproduction across various materials.
State-of-the-art printer built with advanced technology to offer high precision, speed, and stability to your business success.
Equipped with a fast print and dry system, the temperature can be adjusted in real time depending on the actual situation during printing. It is synchronized with printing, energy saving, and emission reduction.
The nozzle can be automatically positioned based on the printing consumable. Anti-collision devices are added at both sides, which can offer more comprehensive safety protection for the nozzle.
The THK double rail imported from Japan is precise and smooth, which ensures that the printer remains stable, noiseless, unobstructed at any parts and has a longer service life.
Built to large amount and weight of paper, it can feed paper evenly, and have short filling and deflation operation time, allowing uniform stress, smooth, and firm receiving on the paper during printing.
| Model | I3200-A1 |
|---|---|
| Ink Type | AQ ink |
| Max. number of colour inks | 4 colours |
| Number of nozzle | 3200 |
| Nozzle pitch /nozzle row | 1/300 inches |
| Nozzle Rows | 8 rows |
| Nozzle Resolution | 300npi/1 column 600npi/2 columns |
| Effective Print Width | 33.8 mm (1.33 inches) |
| Dimensions(LxWxH) | 69.1 x 59.4 x 35.6 mm |
| Weight | 82g |
| Model | XF-19E8PRO |
|---|---|
| Printing Speed | 1PASS:210m²/h 2PASS:109m²/h |
| Printing Width | 75" |
| RIP Software | Standard with Maintop;For Option:RIIN(Only for Hoson board),PhotoPrint, Printfactory |
| Operate System | Windows 11/Windows 10 |
| Temperature / Humidity | 18-30 Celsius/35%-65%Rh |
| Printing Resolution | 3200dpi |
| Print File Format | BMP, TIF, JPG, PDF Etc. |
| Power | 210-230VAC 10A |
| Gross Weight | 1500 KG |
| Package Dimension | L4010*W1180*H2160mm |
Create the artwork using professional design software.
Adjust layout and colors in RIP software.
Print the design onto sublimation transfer paper.
Use a heat press to transfer the image onto polyester fabric (190–210°C, 30–60s).
Bright, durable, and long-lasting results.
